XYZ Robotics RockyLight, a mobile manipulator robot.
Data & sources
robot_type
Mobile Manipulation Robot (MMR)
capabilities
automates mixed case palletizing and case picking for order fulfillment
footprint
1120 mm × 800 mm (3.67 ft × 2.62 ft)
max_gap
50 mm (1.97 in)
operating_temperature
-10°C to 45°C (14°F to 113°F)
protection_class
IP20
remote_control
A wireless tablet with an intuitive human-machine interface (HMI) for effortless remote control and monitoring.
max_payload
25 kg (55.1 lbs)
arm_reach
1800 mm (5.91 ft)
weight
650 kg (1433 lbs)
arm_base_height
900–1800 mm (2.95–5.91 ft)
applicable_case_size
Side length 100–800 mm (3.94–31.5 in)
applicable_pallet_size
Length ≤ 1200 mm, width ≤ 1200 mm, height ≤ 2200 mm
max_step_height
20 mm (0.78 in)
mobility
Omnidirectional
max_speed
2 m/s (6.56 ft/s)
max_slope
10% (5.7°), without accessories percent
