Commercial robotHumanoid
Noetix Bumi
1 editions
Official specs 37
Commercial robotHumanoid1 editions
Lumos Robotics NIX
Lumos Robotics NIX, a humanoid robot.
Data & sources
- Official
- 1
Key specifications
- Height
- 0.89 m
- Weight
- 25.41 kg
- Total degrees of freedom
- 21 DOF
- General payload
- 3 kg
Official edition
Lumos NIX S3 Education edition
Official-source edition/configuration for NIX.
Specifications
Reference ↗Dimensions
| Height | 0.89 m |
|---|---|
| Weight | 25.41 kg |
| Standing dimensions | 0.892 m × 0.445 m × 0.176 m |
| Color options | Black / White |
Actuation
| Total degrees of freedom | 21 DOF |
|---|---|
| Degrees of freedom per arm | 4 DOF |
| Waist degrees of freedom | 1 DOF |
| Degrees of freedom per leg | 6 DOF |
| Peak joint torque | 102 N·m |
Power
| Battery capacity | 282 Wh |
|---|---|
| Runtime | 2 h |
| Charging method | Quick-detach |
| Charging voltage | 220 V |
| Charger output | 67.2 V / 2.5 A |
Sensors
| Rgb camera | Yes |
|---|
Other
| Audio interaction hardware | 4-mic array / speaker / mini wireless microphone |
|---|---|
| Ethernet interface | RJ45 |
| Connectivity | Wi-Fi, 4G, Bluetooth |
| Remote control | Yes |
Manipulation
| General payload | 3 kg |
|---|
Compute
| Base compute | RK3588 |
|---|---|
| Secondary development | Supported |
| Ota update | Supported |
| Education edition performance library | The Education edition supports a broader library of more challenging stunt and dance performances, and opens the SDK for secondary development. |
Reference
01 · Official source
Dimensions; 892*445*176 mm ↗24 linked specifications
- Standing dimensions ↑
- Weight ↑
- Height ↑
- Color options ↑
- Total degrees of freedom ↑
- Degrees of freedom per arm ↑
- Waist degrees of freedom ↑
- Degrees of freedom per leg ↑
- Rgb camera ↑
- Audio interaction hardware ↑
- Battery capacity ↑
- Runtime ↑
- Charging method ↑
- Charging voltage ↑
- Charger output ↑
- Peak joint torque ↑
- General payload ↑
- Ethernet interface ↑
- Connectivity ↑
- Base compute ↑
- Remote control ↑
- Secondary development ↑
- Ota update ↑
- Education edition performance library ↑
Gallery
