Dimensions
| Length | 85 mm |
|---|---|
| Width | 56 mm |
| Dimensions | 85 × 56 mm |
Electrical
| Nominal input voltage | 5 V |
|---|---|
| Logic voltage | 3.3 V |
| Input voltage (nominal) | 5 V |
| Input voltage | 5 V |
Control
| USB interfaces | 5 |
|---|---|
| Wireless interfaces | 802.11ac dual-band Wi-Fi;Bluetooth 5.0 BLE |
| Communication interfaces | GPIO;UART;I2C;SPI;USB;Ethernet;Wi-Fi;Bluetooth |
Mechanical
| Board architecture | single_board_computer Other recorded values
|
|---|---|
| Processor architecture | Arm Cortex-A72 64-bit |
General
| Board kind | sbc_compute Other recorded values
|
|---|---|
| Primary application | robotics;edge_compute;education;linux_sbc |
| Processor vendor | Broadcom |
| Processor | BCM2711 Other recorded values
|
| Processor cores | 4 |
| Processor clock | 1500 MHz |
| RAM | 4096 MB |
| Storage type | microSD |
| Operating system | Raspberry Pi OS;Linux |
| Open-source hardware | No |
| Open-source firmware | No |
| SDK available | Yes |
| ROS support | Yes |
| Firmware updatable | Yes |
| Connectors | 40-pin GPIO; USB-C power; 2x micro-HDMI; MIPI CSI/DSI; Gigabit Ethernet; USB 3/2 |
| Ethernet ports | 1 |
| GPIO | 40 |
| Compute board kind | single_board_computer Other recorded values
|
| SoC | Broadcom BCM2711 |
| GPU / NPU | VideoCore VI GPU |
| Official specifications | 64-bit quad-core Cortex-A72 Raspberry Pi SBC; up to 8GB RAM; dual-band 802.11ac Wi-Fi; Bluetooth 5.0/BLE; Gigabit Ethernet; 2x USB 3.0; 2x USB 2.0; dual micro-HDMI up to 4Kp60; 40-pin GPIO. |
| Clock | 1.5 GHz |
| Memory | 1/2/4/8 GB LPDDR4 |
| Wireless | 2.4 GHz/5 GHz Wi-Fi, Bluetooth 5 |
| USB | 2 × USB 3.0, 2 × USB 2.0 |
| Display | 2 × micro-HDMI |
| Power | USB-C 5 V |
| Storage | microSD |
| Image Gap | official PDF extraction only yielded diagram/pinout image; no product photo uploaded |
