Dimensions
| Length | 55 mm |
|---|---|
| Width | 40 mm |
| Height | 4.7 mm |
| Dimensions | 55 × 40 × 4.7 mm |
Electrical
| Nominal input voltage | 5 V |
|---|---|
| Input voltage (nominal) | 5 V |
| Input voltage | 5 V |
Control
| USB interfaces | 3 |
|---|---|
| Communication interfaces | Gigabit Ethernet;PCIe Gen2 x1;USB;GPIO;UART;I2C;SPI |
Mechanical
| Processor architecture | Arm Cortex-A76 |
|---|
General
| Board kind | compute_module Other recorded values
|
|---|---|
| Primary application | embedded_robot_compute |
| Processor vendor | Broadcom |
| Processor | BCM2712 Other recorded values
|
| Processor cores | 4 |
| Processor clock | 2400 MHz |
| Storage type | eMMC |
| Ethernet ports | 1 |
| GPIO | 28 |
| RAM type | LPDDR4x |
| Memory options | 2/4/8/16 GB LPDDR4x-4267 ECC |
| Storage options | 0/16/32/64 GB eMMC |
| Ethernet | Gigabit PHY |
| PCIe | 1 × Gen 2 x1 |
| USB | 1 × USB 2.0; 2 × USB 3.0 |
| Storage | eMMC |
