Dimensions
| Length | 127 mm |
|---|---|
| Width | 88.9 mm |
| Height | 25.4 mm |
| Weight | 181 g |
| Dimensions | 127 × 88.9 × 25.4 mm |
Electrical
| Minimum input voltage | 20 V |
|---|---|
| Maximum input voltage | 28 V |
| Input voltage | 20 V – 28 V Other recorded values
|
| Input voltage (min) | 20 V |
| Input voltage (max) | 28 V |
Control
| Control modes | step_direction |
|---|
Mechanical
| Board architecture | standalone_board Other recorded values
|
|---|
General
| Board kind | motion_controller Other recorded values
|
|---|---|
| Primary application | multi_axis_motion_control |
| GPIO | 13 |
| Motor channels | 4 |
| Motion axes | 4 |
| Configurable I/O | 13 points |
