Dimensions
| Length | 20.32 mm |
|---|---|
| Width | 17.78 mm |
| Weight | 1.1 g |
| Bandwidth | 120 kHz |
| Dimensions | 20.32 × 17.78 mm |
Electrical
| Minimum current | -20 A |
|---|---|
| Maximum current | 20 A |
| Minimum supply voltage | 4.5 V |
| Maximum supply voltage | 5.5 V |
| Current range | −20 to +20 A |
| Supply voltage | 4.5–5.5 V |
General
| Sensor type | current_sensor |
|---|---|
| Response time | 4 µs |
| Sensitivity | 100 mV/A Other recorded values
|
